Akubela KXPW-B1A960

Power Module
Akubela

Power Module

Akubela KS53-R2-EU​

This KNX power supply, with integrated monitoring function, delivers a stable 30V DC power source for EIB/KNX system. It has two output terminals: one for bus power and signal transmission, and the other for auxiliary power. Its modular design enables easy installation on a 35mm DIN rail. It also includes a reset button to restore the power in case of a fault, ensuring continuous system operation.

Features
Dualoutput: Support two outputs with a total current of
960mA
Overload protection: Automatically cut power and alerts
Short-circuit protection: Automatically cut power and
alerts
Busreset
Specification
Product Model: KXPW-B1A960
Input Voltage: 180 ~ 264VAC
Output Voltage: 30V DC
Output Current: <960mA (total for both
channels)
Number of Channels: 2 channels
Operating Temperature:-5 ~ 45°C
Operating Humidity: 10 ~ 95% RH
(non-condensing)
Product Dimensions: 90×72×64mm
Installation: 35mm DIN rai
